| ブランド名: | SR |
| モデル番号: | HE200BT |
| MOQ: | 10個 |
| 価格: | 13-20usd |
| 支払条件: | LC、T/T |
| 供給能力: | 4000 PCS/日 |
| Image Sensor | Monochrome Imaging CMOS |
| Pixel | 1056*1248 |
| Shutter | Global Exposure |
| Illumination | White LED (Red/Blue LED optional) |
| Aiming | Red Line LED |
| Field of View Angle | Horizontal 40°, Vertical 31° |
| Supported Symbologies (2D) | Aztec Code, Han Xin Code, Data Matrix, MaxiCode, QR Code, Micro QR, MQR, Dot Code, Grid Matrix, Codablock A, Codablock F, PDF417, Micro PDF417 |
| Supported Symbologies (1D) | Codabar, Code11, Code128, ISBT128, Code32, Code39, TLC39, Code93/93i, BC412, UK Plessey, Anker Plessey, EAN-13, EAN-8, GS1, MSI, Telepen, Pharma, PatchCode, UPC-A, UPC-E |
| Reading Precision | ≥3mil |
| Reading Contrast | ≥15% |
| Reading Angle | Tilt ±60°, Rotation ±360°, Skew ±60° |
| Wireless Frequency Band | 433MHz/Bluetooth 4.0 Dual Mode |
| Wireless Communication Distance | 433MHz: 200m in open area; Bluetooth: 20m in open area |
| LCD Display (Optional) | Barcode content display, battery level display, basic configuration |
| Battery | 2600mAh; Removable battery |
| Charging Time | 4~6 hours |
| Continuous Scanning Time | >8 hours (at 1 scan per second) |
| Storage Capacity (Storage Mode) | >5000 barcodes |
| Base Communication Interface | USB or RS232 |
| Prompt Method | LCD display, LED (non-LCD version), buzzer, vibration |
| Dimension | Scanner: 21176100mm; Base: 26210166mm |
| Weight | Scanner: 400g; Base: 350g |
| Operating Voltage | DC5V±10% |
| Operating Current | 320mA@5V |
| Standby Current | 180mA@5V |
| Operating Temperature | -10℃~50℃ |
| Storage Temperature | -20℃~70℃ |
| Relative Humidity | 5%~95% (no condensation) |
| Drop Resistance | Withstands 50 drops from 1.5m height in air |
| Ambient Illumination | 0~100000LUX |
